Product Overview
The MGC Series Fixed Mining Wagon is engineered for reliability and efficiency in demanding underground and surface mining operations. Built with robust materials and a solid, non-tipping design, these mine cars provide a safe and stable method for transporting ore, rock, and other bulk materials through rail tracks in tunnels and mines.
The MGC series offers a range of sizes and capacities, from the compact MGC1.1-6 to the high-volume MGC3.3-9, ensuring a perfect match for your specific haulage requirements. Our fixed mine cars are synonymous with low maintenance, long service life, and exceptional performance under heavy loads.
Key Features & Advantages
Heavy-Duty Construction
Fabricated from high-strength steel plate and structural sections for maximum durability and impact resistance.
Fixed Body Design
Rigid, non-dumping body provides unparalleled stability and safety during transport, preventing accidental spills.
High-Capacity Range
Volumetric capacities from 1.1 m³ to 3.3 m³ cover various production needs, optimizing your material flow.
Optimized for Standard Gauges
Available in both 600mm and 900mm track gauges, compatible with most mining rail systems worldwide.
Superior Traction & Coupling
Standardized 60 KN traction capacity and uniform 320mm coupling height ensure easy integration with existing setups.
Low Maintenance Design
Simple, robust construction with minimal moving parts reduces downtime and lowers operating costs.
Technical Specifications
Detailed parameters of MGC Series Fixed Mining Wagons for comparison and selection:
| Parameter | MGC1.7-6 | MGC1.7-9 | MGC1.1-6 | MGC3.3-9 |
|---|---|---|---|---|
| Volume (m³) | 1.7 | 1.7 | 1.1 | 3.3 |
| Theoretical Capacity (T) | 1.5 | 1.5 | 1 | 3 |
| Max. Load (T) | 2.7 | 2.7 | 1.8 | 5.3 |
| Gauge (mm) | 600 | 900 | 600 | 900 |
| Wheel Base (mm) | 750 | 600 | 550 | 1100 |
| Wheel Diameter (mm) | 300 | 350 | 300 | 350 |
| Traction (KN) | 60 | 60 | 60 | 60 |
| Traction Height (mm) | 320 | 320 | 320 | 320 |
| Overall Size (L*W*H mm) | 2400x1050x1200 | 2100x1150x1300 | 2000x880x1150 | 3450x1320x1300 |
| Weight (≤kg) | 720 | 970 | 610 | 1320 |
Applications
Our MGC Fixed Mine Cars are the workhorses of continuous mining cycles. The rigid body design makes them ideal for:
Coal Mining: Transporting raw coal from the face to processing areas or shaft bottom.
Metal & Mineral Mining: Hauling ore, waste rock, and other extracted materials.
Tunnel Construction: Moving muck and supplies during railway, highway, or hydro-tunnel projects.
Ready to Enhance Your Mining Operations?
Get a customized quote for the MGC Series Fixed Mining Wagon that best fits your requirements. Our engineering team is ready to assist you.
Request a Quote
