Mining Light Steel Rail
- Superior Abrasion Resistance
- Heavy-Duty Material Strength
- Multiple Size & Weight Options
- Customizable Length Solutions
Mining Light Steel Rail
Durable & Efficient Transportation Solution for Mining Operations
Product Introduction
Mining light rail is an essential component in underground transportation systems, designed to support the efficient movement of ore, materials, and personnel in mining operations. These rails are specifically engineered to withstand harsh environments, including heavy loads, moisture, and abrasive conditions.
They are commonly used in tunnels, shafts, and mining corridors to facilitate the smooth operation of rail-bound haulage systems, such as locomotives and mine carts.
Our mining light rails are available in various specifications, including 8kg, 12kg, 15kg, 18kg, 22kg, 24kg, and 30kg, with lengths ranging from 6 to 12 meters.
Material Options
Our rails are manufactured using two primary materials: Q235 and 55Q, each suited for different applications and operational demands.
Q235 Material
Q235 is a common carbon structural steel with good strength and weldability, suitable for general-purpose mining applications with moderate loads and wear conditions.
55Q Material
55Q is a higher-quality carbon steel with enhanced tensile strength, hardness, and abrasion resistance. This makes it ideal for heavy-duty mining operations where rails are subjected to extreme stress, impact, and wear.
Why Choose Our Mining Light Rails?
Durability: Our rails are made from high-quality materials, ensuring long service life even in demanding environments.
Versatility: We offer a wide range of sizes and weights to meet specific operational needs.
Precision Engineering: Each rail is manufactured to exact dimensions for seamless integration into existing systems.
Material Options: Customers can choose between Q235 for standard applications and 55Q for heavy-duty use.
Reliable Support: We provide tailored solutions and technical support to help optimize your mining transportation infrastructure.
Technical Specifications
Below are the detailed specifications for our mining light rail products. Hover over rows for better readability.
| Type | Head Width(mm) | Height(mm) | Bottom Width | Web Thickness(mm) | Theory Weight(kg/m) | Material | Length |
|---|---|---|---|---|---|---|---|
| 8kg | 25 | 65 | 54 | 7 | 8.42 | Q235 | 6-12m |
| 12kg | 38.1 | 69.85 | 69.85 | 7.54 | 12.2 | Q235/55Q | 6-12m |
| 15kg | 42.86 | 79.37 | 79.37 | 8.33 | 15.2 | Q235/55Q | 6-12m |
| 18kg | 40 | 90 | 80 | 10 | 18.06 | Q235/55Q | 6-12m |
| 22kg | 50.8 | 93.66 | 93.66 | 10.72 | 22.3 | Q235/55Q | 6-12m |
| 24kg | 51 | 107 | 92 | 10.9 | 24.46 | Q235/55Q | 6-12m |
| 30kg | 60.33 | 107.95 | 107.95 | 12.3 | 30.1 | Q235/55Q | 6-12m |
Ready to Enhance Your Mining Operations?
Choose our mining light rails for a reliable, efficient, and cost-effective solution to your mining transportation challenges.
