Product Overview
The SZJ Series Deep Cone Thickener is a state-of-the-art industrial solution designed for efficient slurry concentration and clarification. Engineered for optimal performance in demanding environments, this equipment delivers unparalleled results in dewatering applications across multiple industries.
Key Features
High Efficiency
Processing capacity of 100-150m³/㎡.h with underflow concentration exceeding 50% and overflow concentration below 1g/L.
Mechanical Agitation
Equipped with mechanical stirring device to accelerate sedimentation and prevent material accumulation at the cone bottom.
Advanced Design
Internal plastic inclined plates significantly increase sedimentation area, enhancing concentration efficiency.
Cost-Effective
Compact footprint, reduced investment, energy efficiency, low operating costs, and simplified management.
Technical Specifications
| Model | Working Diameter (mm) | Volume (m³) | Capacity (m³/h) | Speed (r/min) | Power (KW) |
|---|---|---|---|---|---|
| SZJ-4 | 4000 | 47 | 100-150 | 1.78 | 3 |
| SZJ-5 | 5000 | 72 | 180-250 | 1.78 | 3 |
| SZJ-6 | 6000 | 99 | 260-380 | 1.78 | 3 |
| SZJ-8 | 8000 | 186 | 400-550 | 1.78 | 7.5 |
| SZJ-10 | 10000 | 460 | 420-760 | 0-2 | 7.5 |
Industrial Applications
The SZJ Series Deep Cone Thickener is engineered for diverse industrial applications requiring efficient slurry concentration and water clarification:
Municipal Wastewater
Coal Slurry Water
Mineral Processing
Power Industry
Chemical Industry
Technical Highlights
Superior Concentration: Achieves underflow concentration >50% and overflow clarity<1g/l
Enhanced Sedimentation: Mechanical agitation prevents material buildup and accelerates settling
Optimized Design: Plastic inclined plates maximize effective sedimentation area
Operational Efficiency: Low energy consumption with minimal maintenance requirements
Robust Construction: Durable materials ensure longevity in harsh industrial environments
